The Mollier Diagram
- by Jeroen Fijan 270320. We choose an auxiliary point on the.
Ukuran Box Subwoofer 15 Model Martin Sw215 Mantap Bantoel Com Speaker Desain Pengeras Suara
The diagram shown at the end of part 1 shows no limit to the amount of water that can be evaporated into air.

The mollier diagram. Mollier work many years with his students to enhance his diagrams and works on other problems in thermodynamicsrefrigerationhydraulics and gas engines. The Mollier diagram also called the enthalpy h entropy s chart or h-s chart is a graphical representation of thermodynamic properties of materials. While weve done our best to make this as easy as possible to understand it does require some knowledge about what the lines stand for so if youre unfamiliar with the diagram please read the first and second parts of this blog.
A Mollier diagram is a graphic representation of the thermodynamic properties of steam. The Mollier hx-diagram quantities Air density ρ The vertical orange axis to the extreme left. Read the air density by following the slanting orange lines in the diagram.
Molliers H-S diagram Enthalpy v Entropy was a logical extension of the T-S diagram Temperature v Entropy first proposed by Gibbs retaining the advantages of T-S diagrams but introducing several new advantages. The Mollier diagram is the representation of the properties of water and water vapor. The term Mollier diagram named after Richard Mollier 1863-1935 refers to any diagram that features Enthalpy on one of the coordinates.
The diagram was created in 1904 when Richard Mollier plotted total heat against entropy. A typical chart covers a pressure range of 0011000 bar and temperatures up to 800 degrees Celsius. An enthalpyentropy chart also known as the HS chart or Mollier diagram plots the total heat against entropy describing the enthalpy of a thermodynamic system.
The Mollier diagram is a variant of the psychrometric chart. The h-s diagram is one in which Enthalpy. It shows enthalpy in terms of internal energy pressure and volume using the relationship or in terms of.
Compressor performance cannot be accurately predicted without detailed knowledge of the behavior of the gas or gases involved. Cooling coil Heater capacity Steam humidifie We start by establishing the outside and inside conditions. The Mollier diagram is a graphic representation of the relationship between air temperature moisture content and enthalpy and is a basic design tool for building engineers and designers.
In general it is a relationship between enthalpy measure of the energy of a thermodynamic system air temperature and moisture content. For reference and computational purposes steam tables and Mollier Enthalpy-Entropy diagrams are included in Appendix B. This is a quick no-nonsense guide to using the Mollier diagram.
He carried out meticulous calculations for every state and property of air. At the 1923 Thermodynamics Conference held in Los Angeles it was decided to name in his honor as a. A main H-S coordinate system Enthalpy-Entropy is used.
A typical H-S Mollier diagram for a thermodynamic fluid such as steam is shown in Figure 1. Most engineers understand the role units play in definition and verification of the engineering concepts principles equations and analytical techniques. The Mollier diagram - 2.
We know however that there is a limit beyond which water can only exist as a fog of liquid water drops. How to use a Mollier diagram - by Jeroen Fijan 230420. The Psychrometric Chart is also known as the Mollier-Diagram when the axes are flipped.
This diagram is widely used in mechanical engineering and HVAC technology and plots the. Fixing the value of any two properties defines the value of all the others. This is our field of operation which.
There are six interrelated properties that define the state of steam. Thus fixing the values of Enthalpy and Entropy is sufficient to define Temperature Pressure and Internal Energy of the steam. Table 47Draw in the Mollier diagram at the 14C point of the saturation curve a the state change line of the adiabatic humidification and b an auxiliary line associated with the wet bulb temperature measurement by means of which the state can be defined.
Also service technician make good use of the Mollier diagram while installing or maintaining installations that cool air heat air steam refrigerate etc. Air density is the specific gravity measured in kgm3. Commonly used Mollier diagrams are the enthalpy-entropy or h-s diagram below and the pressure-enthalpy diagram illustrated at the bottom of this page.
Air temperature t The vertical pink axis to the left with corresponding slightly slanting horizontal gridlines. Download and print Mollier Diagram for Water - Steam. Mollier part 3.
Mollier diagrams are readily available for most pure gases at conventional pressures and temperatures. The diagram is used to engineer an air handling unit. H 2 O Mollier Diagram Pressure-Enthalpy Diagram Based on the Scientific IAPWS-95 Formulation Mollier Chart in Metric Units Excel file 342 KB.
Therefore most thermodynamic concepts principles and computational. Online Mollier-Diagram With a Mollier Diagram also know as Psychrometric Chart you can draw processes of humid moist air and calculate air conditions. However in cryogenic areas or at very high pressure some gas behaviors are difficult to.
The ordinate h is enthalpy and the abscissa s is entropy. The water vapour concentration is expressed in the Mollier diagram as kgkg of dry air. In this example we will show you how to calculate the following aspects of a unit using the Mollier diagram.
Using the graphical representation of the relationships of various steam conditions computations made for analysis of various cycles and processes can be performed quickly with a fairly high. The diagram below can be used to determine enthalpy versus entropy of water and steam. The chart is is combined with the Relative Humidity lines and the Enthalpy to calculate the change in total internal energy.
Richard Mollier was a professor of Applied Physics and Mechanics and a pioneer of experimental research in thermodynamics in the late 19th century. The term Mollier diagram named after Richard. The pressure of air is p 1 bar.
Mollier diagram part 2. The Mollier diagram is useful when analyzing the performance of adiabatic steady-flow processes such as flow in nozzles diffusers turbines and compressors. This diagram is widely used in mechanical engineering and HVAC technology and plots the Temperature versus the Absolute Humidity.
Drawn with SteamTab using the IAPWS-95 formulation. Download and print Mollier diagram.
